Bhavesh Tube Fittings is a reputed manufacturer and supplier based in Dubai, UAE, specializing in quality tube fittings and valves. Committed to excellence we offer a comprehensive range of products including the durable Stainless Steel 316Ti Ball Valve. Designed for excellent performance in demanding applications this round valve offers exceptional corrosion resistance and reliability, making it the ideal choice for a variety of industries Our focus on quality and customer satisfaction ensures see that we meet the evolving needs of our customers.
Stainless steel 316Ti ball valves are manufactured primarily from a chromium-nickel-molybdenum alloy with the addition of titanium for increased corrosion resistance and high temperature Typical products contain 16-18% chromium, 10-14% nickel , 2-3% molybdenum and up to 0.7% titanium. The mechanical properties include a yield strength of 30-40 ksi and a tensile strength of 70-80 ksi. Advantages include excellent pitting and crack corrosion resistance, high strength and high temperature durability, making it ideal for chemical, petrochemical and marine applications
VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
BODY TYPE | BAR STOCK |
BRAND NAME | TU-LOK |
PACKING DETAILS | BOX PACKING, WOODEN PALLET |
EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
SS 316Ti | min. | – | 10.0 | – | – | – | – | – | 16.0 | 2.00 |
max. | 0.08 | 14.0 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 18.0 | 3.00 |
Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness |
Rockwell B (HR B) max | ||||
SS 316Ti | 515 | 35 | 205 | 75 |
STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
SS 316Ti | S31635 | 1.4571 | Z6CNDT17‐12 | X6CrNiMoTi17-12-2 | SUS 316Ti | 320S31 | 08Ch17N13M2T |
Contact us to get a quick quote for your requirement.
Stainless steel 316Ti ball valves are widely used in a variety of industries due to their corrosion resistance and high operating temperature Common applications include oil and gas, chemical processing, and water a for operation, where it controls flow with minimum pressure. Their titanium coating enhances pitting, cracking and corrosion resistance, making them ideal for the marine environment. Additionally, these valves are used in the food and pharmaceutical industries for hygienic applications, making them reliable and safe in critical applications Their rugged construction lasts for long periods of time and reduced maintenance.
Please feel free to contact us if you need any further information or for enquiry.
