Bhavesh Tube Fittings is a leading manufacturer and distributor of high-quality Alloy 20 Ball Valves, designed to meet the stringent demands of industries such as chemical processing, pharmaceuticals, and petrochemicals. Renowned for their exceptional resistance to corrosion, particularly against sulfuric acid and chloride stress corrosion cracking, these valves provide reliable performance in harsh environments. With a commitment to precision engineering and quality assurance, Bhavesh Tube Fittings ensures that every Alloy 20 Ball Valve offers durability, leak-proof operation, and longevity, making them the trusted choice for critical industrial applications worldwide.
Alloy 20 ball valves are made from a nickel-iron-chromium alloy with added molybdenum and copper for enhanced corrosion resistance. The mechanical properties include high strength, durability, and resistance to pitting, crevice corrosion, and stress corrosion cracking, especially in acidic environments. The valve operates efficiently at both high and low temperatures. Advantages include excellent performance in chemical processing industries, resistance to sulfuric acid, and versatility across a wide range of corrosive environments. This makes them ideal for handling harsh chemicals and extending valve service life.
STANDARD | API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
BODY TYPE | BAR STOCK |
BRAND NAME | TU-LOK |
PACKING DETAILS | BOX PACKING, WOODEN PALLET |
EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Grade | % | Ni | Cr | Mo | Cu | Nb | C | Mn | Si | P | S |
Alloy 20 | Min. | 32 | 19 | 2 | 3 | 0.1 | 1 | ||||
Max. | 38 | 21 | 3 | 4 | 0.3 | 0.02 | 2 | 0.7 | 0.02 | 0.005 |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi – 80000 , MPa – 551 | Psi – 35000 , MPa – 241 | 30 % |
At Bhavesh Tube Fittings, we are a leading supplier, manufacturer, and exporter of Alloy 20 Ball Valve in Dubai, UAE. Our state-of-the-art manufacturing facilities, strategically located in the UAE, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.
Bhavesh Tube Fittings is a leading supplier and stockist of premium Alloy 20 Ball Valve in Dubai, UAE. Our products find extensive application across diverse industries, and we are dedicated to delivering outstanding service while ensuring high customer satisfaction. Our specialized finishing techniques distinguish us in the metal industry, enhancing the performance and durability of our valves. We are committed to consistently providing top-quality Monel Manifold Valves while effectively addressing the unique needs of our customers.
Contact us to get a quick quote for your requirement.
Alloy 20 ball valves are widely used in industries that handle highly corrosive substances. They are commonly found in chemical processing plants, particularly for handling sulfuric acid, phosphoric acid, and other harsh chemicals. These valves are also used in petrochemical, pharmaceutical, and food processing industries due to their resistance to corrosion and contamination. Additionally, they are ideal for environments with high chloride levels, such as seawater and brine processing, and are utilized in waste treatment facilities where corrosion resistance and durability are critical.
Please feel free to contact us if you need any further information or for enquiry.
