Home > Tantalum Ball Valve
Bhavesh Tube Fittings is a leading manufacturer and distributor specializing in high-quality tantalum ball valves. Renowned for our commitment to excellence, we provide innovative solutions that meet the demands of various industries, including chemical processing and aerospace. Our tantalum ball valves are engineered for superior corrosion resistance and durability, ensuring reliable performance in the most challenging environments. With a focus on precision and customer satisfaction, we offer a comprehensive range of fittings tailored to your specific needs. Trust Bhavesh Tube Fittings for exceptional quality and service in the world of tantalum ball valves.
Tantalum ball valves are primarily composed of tantalum, a highly corrosion-resistant metal known for its exceptional durability and strength. Mechanically, tantalum exhibits high tensile strength, excellent fatigue resistance, and a melting point of 3,017°C (5,477°F), making it suitable for extreme environments. The advantages of tantalum ball valves include outstanding resistance to aggressive chemicals, low permeability to gases, and minimal maintenance requirements. Their reliability enhances system performance while ensuring safety in critical applications, making them ideal for industries such as chemical processing, pharmaceuticals, and aerospace.
STANDARD | API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
BODY TYPE | BAR STOCK |
BRAND NAME | TU-LOK |
PACKING DETAILS | BOX PACKING, WOODEN PALLET |
EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Element |
R05200 (%,Max) |
R05400 (%,Max) |
R05252 (Ta-2.5W) (%,Max) |
R05255 (Ta-10W) (%,Max) |
C |
0.01 |
0.01 |
0.01 |
0.01 |
O |
0.015 |
0.03 |
0.015 |
0.015 |
N |
0.01 |
0.01 |
0.01 |
0.01 |
H |
0.0015 |
0.0015 |
0.0015 |
0.0015 |
Fe |
0.01 |
0.01 |
0.01 |
0.01 |
Mo |
0.02 |
0.02 |
0.02 |
0.02 |
Nb |
0.1 |
0.1 |
0.5 |
0.1 |
Ni |
0.01 |
0.01 |
0.01 |
0.01 |
Si |
0.005 |
0.005 |
0.005 |
0.005 |
Ti |
0.01 |
0.01 |
0.01 |
0.01 |
W |
0.05 |
0.05 |
2.0-3.5 |
9.0-11.0 |
Ta |
Remainder |
Remainder |
Remainder |
Remainder |
Properties | Metric | Imperial |
Density | 16.65 g/cm3 | 0.6015 lb/in3 |
Melting point | 2850 °C | 5162°F |
Boiling point | 6000 °C | 10832°F |
At Bhavesh Tube Fittings, we are a leading supplier, manufacturer, and exporter of Tantalum Ball Valve in Dubai, UAE. Our state-of-the-art manufacturing facilities, strategically located in the UAE, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.
Bhavesh Tube Fittings is a leading supplier and stockist of premium Tantalum Ball Valve in Dubai, UAE. Our products find extensive application across diverse industries, and we are dedicated to delivering outstanding service while ensuring high customer satisfaction. Our specialized finishing techniques distinguish us in the metal industry, enhancing the performance and durability of our valves. We are committed to consistently providing top-quality Monel Manifold Valves while effectively addressing the unique needs of our customers.
Contact us to get a quick quote for your requirement.
Tantalum ball valves are widely used in various industries due to their exceptional corrosion resistance and durability. They are commonly employed in chemical processing plants for handling aggressive acids and alkalis, ensuring safe and efficient flow control. In the pharmaceutical industry, tantalum valves facilitate the handling of sensitive materials without contamination. Additionally, they find applications in the aerospace sector for high-performance systems requiring reliable sealing under extreme conditions. Their ability to withstand harsh environments makes tantalum ball valves essential for maintaining safety and efficiency in demanding applications.
Please feel free to contact us if you need any further information or for enquiry.
