Bhavesh Tube Fittings is the leading manufacturer of high quality nickel ball valve in Dubai, UAE. Known for their corrosion resistance and excellent durability. These valves are engineered for reliable performance in a variety of industrial applications. Made of premium nickel, it is suitable for handling aggressive chemicals and high-pressure systems. With a commitment to quality and customer satisfaction We ensure that their nickel ball valves meet international standards making them desirable for industries such as chemical processing and oil & gas also marine exercise.
Nickel ball valves are made primarily of nickel alloy typically containing 65-75% nickel with small amounts of copper and iron and other elements. This design provides excellent corrosion resistance especially in harsh environments. Technically nickel ball valves exhibit a tensile strength of around 550-800 MPa and a yield strength of 240-350 MPa. Ensuring durability and reliability advantages. Include resistance to pitting and stress corrosion cracking a it stands out making it suitable for the chemical industry and marine applications as well as oil and gas. Become a model for projects that effectively handle strong water and high-pressure conditions.
STANDARD | ASTM A494 / ASME SA494 API 600/BS1414, ASME B 16.34, ASME B 16.10, ASME B 16.5, API 598/BS EN 12266-1,ASME B 16.25 |
VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
BODY TYPE | BAR STOCK |
PACKING DETAILS | BOX PACKING, WOODEN PALLET |
APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min | – |
201 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min | – |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Contact us to get a quick quote for your requirement.
Nickel ball valves are often used in applications that require high corrosion resistance and reliable operation. They are ideal for chemical processing, where aggressive chemicals and corrosive liquids, including acids and bases, are handled. In the oil and gas industry these valves are used in pipelines and offshore platforms because in addition to their durability and high-pressure resistance. Nickel ball valves are suitable for marine applications. Making it more efficient in salt water. Versatility makes it necessary to ensure the safety and efficiency of industrial processes and systems.
Please feel free to contact us if you need any further information or for enquiry.
