Bhavesh Tube Fittings is a leading manufacturer and supplier of stainless steel 304 ball valves in Dubai, UAE. Known for their unique and durable properties these valves are engineered to handle a variety of technical applications. Made from high-quality 304 stainless steel it offers excellent corrosion resistance also making it ideal for harsh environments. Bhavesh Tube Fittings is committed to providing reliable, durable, and cost-effective valve solutions to ensure customer satisfaction that meets the needs of all industries in the UAE.
Stainless steel 304 ball valve is made of steel containing 18-20% chromium, 8-10.5% nickel, carbon, manganese and trace amounts of silicon, to ensure excellent corrosion resistance. Mechanically it provides a suction force of approx 515 MPa and a yield strength of 205 MPa , with a hardness of about 90 HRB. These valves work best in temperatures between -29°C to 400°C. Advantages include exceptional resistance to corrosion and oxidation, durability, ease of maintenance, and suitability for high pressure and high temperature applications, making it ideal for use in the chemical, fuel and water industries.
VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
BODY TYPE | BAR STOCK |
PACKING DETAILS | BOX PACKING, WOODEN PALLET |
APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Grade | Mn | C | Si | S | Cr | P | N | Mo | |
304 | minimum maximum | – 2.0 | – 0.08 | – 0.75 | – 0.030 | 18.0 20.0 | – 0.045 | – 0.10 | – |
304L | minimum maximum | – 2.0 | – 0.030 | – 0.75 | – 0.030 | 18.0 20.0 | – 0.045 | – 0.10 | – |
304H | minimum maximum | – 2.0 | 0.04 0.10 | – 0.75 | – 0.030 | 18.0 20.0 | -0.045 | – | – |
Grade | (% in 50mm) Elongation minimum | 0.2% Proof Yield Strength (MPa) minimum | Strength of Tensile (MPa) minimum | Hardness | |
Brinell (HB) max | Rockwell B (HR B) max | ||||
304 | 40 | 205 | 515 | 201 | 92 |
304L | 40 | 170 | 485 | 201 | 92 |
304H | 40 | 205 | 515 | 201 | 92 |
Grade | British | Euronorm | UNS No. | SS | JIS | ||
European Standards | British Standards | Name | DIN No. | ||||
304 | 58E | 304S31 | X5CrNi18-10 | 1.4301 | S30400 | 2332 | SUS 304 |
304L | – | 304S11 | X2CrNi19-11 | 1.4306 | S30403 | 2352 | SUS 304L |
304H | – | 304S51 | X6CrNi18-11 | 1.4948 | S30409 | – | – |
Contact us to get a quick quote for your requirement.
Stainless steel 304 ball valves are widely used in various industries due to their corrosion resistance and durability. In chemicals and fuels, flows of water and corrosive gases are controlled. In the food and beverage industry. Water products are handled while maintaining hygiene standards. Water treatment plants use it to control water flow while HVSCs use it to control flow. Used in pharmaceutical, oil and gas, and marine applications. It provides reliable performance in high-pressure and high-temperature environments, as well as proper water management and shutdown.
Please feel free to contact us if you need any further information or for enquiry.
