Home > Stainless Steel > Stainless Steel 310 Ball Valve
Bhavesh Tube Fittings s is a renowned manufacturer and supplier based in Dubai, UAE, specializing in many high quality tube fittings and industrial components With a strong focus on accuracy, reliability and customer satisfaction Bhavesh Tube Fittings handles a variety of projects, provides solutions for demanding applications. Their premium offerings include the Stainless Steel 310 Ball Valve, which is known for its very high temperature resistance, durability and corrosion resistance in the petrochemical, power generation, and oil and gas industries It excels in difficult areas
Stainless steel 310 ball valves are made of an alloy of 25% chromium and 20% nickel, for excellent resistance to oxidation and corrosion at high temperatures (up to 1150°C) Mechanical properties include 515 MPa tensile strength, 205 MPa yield strength and 40 % elongation. These valves provide high strength, good weldability and toughness even at cryogenic temperatures. Their main advantage is that they resist exceptional heating cycles, making them ideal for chemicals and heating fuels
VALVE SIZE |
1/8″ TO 2″ / 6 MM TO 50 MM |
THREAD |
NPT, BSPP, BSPT, JIC, METRIC, UNF |
CONNECTION |
THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
FUNCTION |
2 WAY, 3 WAY, 4 WAY, 5 WAY, |
PRESSURE RATING |
1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
SEAL RING MATERIAL |
PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
STANDARD |
ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
MEDIA |
HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
MEDIA TEMPERATURE |
(-120* C TO 500*C )RANGE AS PER PRESSURE |
BODY TYPE |
BAR STOCK |
PACKING DETAILS |
BOX PACKING, WOODEN PALLET |
APPLICATION |
MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
SS Grade |
Mn |
Si |
C |
N |
Cr |
S |
P |
Mo |
Ni |
|
310 |
minimum
maximum |
–
2.00 |
–
1.50 |
–
0.25 |
– |
24.0
26.0 |
–
0.030 |
–
0.045 |
– |
19.0
22.0 |
310S |
minimum
maximum |
–
2.00 |
–
1.50 |
–
0.08 |
– |
24.0
26.0 |
–
0.030 |
–
0.045 |
– |
19.0
22.0 |
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
Stainless steel 310S Valves | 515 | 205 | 40 | 95 | 217 |
Stainless Steel 310 Valves | 515 | 205 | 40 | 95 | 217 |
STANDARD | UNS | WERKSTOFF NR. | EN | BS | JIS |
SS 310 | S31000 | 1.4845 | X8CrNi25-21 | 310S16 | SUS 310S |
Contact us to get a quick quote for your requirement.
Stainless steel 310 ball valves are widely used in various industries due to their excellent corrosion resistance and high temperature Common applications include chemical processing, oil and gas, energy generation and water supply effective. They are ideal for aggressive media and high-pressure systems. Their durable construction ensures reliability in extreme conditions, making them suitable for operations both onshore and offshore. Also, stainless steel 310 circular valves are used in hygienic applications in the food and beverage industry, due to their inertness and ease of maintenance
Please feel free to contact us if you need any further information or for enquiry.
