Bhavesh Tube Fittings is a leading manufacturer and distributor based in Dubai, UAE, specializing in high-quality tube fittings for various industries. Known for their precise product design, they offer a wide range of features including interchangeable Adjustable locknut elbows designed to provide a secure leak-proof connection thanks to their commitment to quality, innovation, and customer satisfaction across the region in the oil, gas, petrochemical, and construction industries Being a trusted partner for customers, Bhavesh Tube Fittings ensures reliable solutions for critical applications.
An adjustable locknut cohn, usually made of materials such as brass or stainless steel, used in piping systems has an angle of 90 degrees Includes copper, zinc (brass), or steel, chromium, and nickel (for stainless steel). Technical features include high tensile strength, corrosion resistance and durability. It allows for secure communication with the ability to easily change faces, and provides configuration flexibility. The locknut ensures a tight fit, preventing leaks. The main advantages are ease of adaptation to high-pressure and low-pressure systems, reusability, and reliability.
STANDARD | DIN 2353/ ISO 8434-1 |
MATERIAL | MS, CS, SS 304, SS 304L, SS 316, SS 316L, SS 316TI ( 1.4571), BRASS, COPPER, DUPLEX, SUPER DUPLEX, INCONEL, MONEL, HASTELLOY, 904L, 6MO, TITANIUM, ALUMINUM, ALLOY 20 |
SERIES | LL- LOW PRESSURE, L- MEDIUM PRESSURE, S- HIGH PRESSURE |
WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
(MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
(HEAVY)S SERIES – 200 BAR TO 800 BAR | |
SIZE RANGE | LL SERIES – 4LL TO 12LL |
L SERIES – 6L TO 42L | |
S SERIES – 6S TO 38S | |
BODY TYPE | FORGED, BAR STOCK |
ACCESSORIES | O-RING, DOWTY SEAL, COPPER WASHER, ED SEAL, CUTTING RING, NUT |
O-RING & SEALS | NBR ( -35*C TO 100* C ) VITON (-25*C TO 200* C) , PTFE – (-60*C TO 240*) |
SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED, YELLOW PLATTING, BLACK PHOSPHATE, |
STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
At Bhavesh Tube Fittings, we are the largest supplier, manufacturer, and exporter of Adjustable Locknut Elbow in Dubai, UAE. Our advanced manufacturing facilities, strategically positioned in the UAE, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
Series | Tube ?D1 | F1 | F | L | A | L1 | P |
L | 6 | 14 | 12 | 27 | 12 | 26 | M 12 x 1.5 |
light | 8 | 17 | 12 | 29 | 14 | 27.5 | M 14 x 1.5 |
PN 315 | 10 | 19 | 14 | 30 | 15 | 29 | M 16 x 1.5 |
12 | 22 | 17 | 32 | 17 | 29.5 | M 18 x 1.5 | |
15 | 27 | 19 | 36 | 21 | 32.5 | M 22 x 1.5 | |
18 | 32 | 24 | 40 | 23.5 | 35.5 | M 26 x 1.5 | |
PN 160 | 22 | 36 | 27 | 44 | 27.5 | 38.5 | M 30 x 2 |
28 | 41 | 36 | 47 | 30.5 | 41.5 | M 36 x 2 | |
35 | 50 | 41 | 56 | 34.5 | 51 | M 45 x 2 | |
42 | 60 | 50 | 63 | 40 | 56 | M 52 x 2 | |
S | 6 | 17 | 12 | 31 | 16 | 27 | M 14 x 1.5 |
heavy | 8 | 19 | 14 | 32 | 17 | 27.5 | M 16 x 1.5 |
PN 630 | 10 | 22 | 17 | 34 | 17.5 | 30 | M 18 x 1.5 |
12 | 24 | 17 | 38 | 21.5 | 31 | M 20 x 1,5 | |
14 | 27 | 19 | 40 | 22 | 35 | M 22 x 1.5 | |
PN 400 | 16 | 30 | 24 | 43 | 24.5 | 36.5 | M 24 x 1.5 |
20 | 36 | 27 | 48 | 26.5 | 44.5 | M 30 x 2 | |
25 | 36 | 36 | 54 | 30 | 50 | M 36 x 2 | |
30 | 50 | 41 | 62 | 35.5 | 55 | M 42 x 2 | |
PN 315 | 38 | 60 | 50 | 72 | 41 | 63 | M 52 x 2 |
Contact us to get a quick quote for your requirement.
Bhavesh Tube Fittings is a leading supplier and stockist of premium Adjustable Locknut Elbow in Dubai, UAE. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
Adjustable locknut elbows are commonly used in electrical circuit systems to connect the conduit at different angles while maintaining a secure, adjustable connection and are particularly useful in tight or awkward standard locations rigid fittings cannot allow for changes in direction. The locknut keeps the elbow securely in place and prevents it from loosening due to vibration or movement. These fittings are used in industrial, commercial and residential wiring systems to provide flexibility during installation while ensuring continuous ground clearance and protecting the wiring from damage
