Bhavesh Tube Fittings is a premier manufacturer and supplier based in Dubai, UAE, offering a wide range of high-performance tube fittings for various industrial applications. Among their key offerings are Titanium Tube Fittings, known for their exceptional strength, lightweight nature, and outstanding resistance to corrosion. These fittings are ideal for industries such as aerospace, marine, and chemical processing. With state-of-the-art facilities and a commitment to quality, Bhavesh Tube Fittings delivers reliable solutions that meet stringent international standards.
Titanium Tube Fittings are primarily composed of titanium, which can be alloyed with elements like aluminum and vanadium to enhance strength and durability. They offer excellent mechanical properties, including high tensile strength, lightweight structure, and exceptional resistance to corrosion, particularly in harsh environments. These fittings can withstand extreme temperatures, making them suitable for high-pressure and high-temperature applications. Their biocompatibility also makes them ideal for medical and aerospace industries. The main advantages include superior longevity, corrosion resistance, and an optimal strength-to-weight ratio, ensuring reliable performance in demanding conditions.
Specifications | ASTM B366 / ASME SB366 |
---|---|
Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
Working Pressures | Upto 2000 to 6000 PSI |
Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
Equivalent To | SWAGELOK, PARKER, DK-LOK, HOKE |
Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
Tube Fitting uses & application |
|
Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 |
Grade | Ti | C | Fe | H | N | O | Al | V |
Titanium Tube Fittings | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Titanium Tube Fittings | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Bhavesh Tube Fittings, we are the largest supplier, manufacturer, and exporter of Titanium Tube Fittings in Dubai, UAE. Our advanced manufacturing facilities, strategically located in the UAE, allow us to provide high-quality solutions tailored to your specific requirements. With a substantial inventory of over 16,000 tons of top-grade stainless steel materials, we are well-equipped to meet your needs promptly. Our commitment to excellence and efficiency ensures that we consistently maintain available stock to support your demands.
STANDARD | WERKSTOFF NR. | UNS |
Titanium Tube Fittings | 3.7035 | R50400 |
Contact us to get a quick quote for your requirement.
Titanium Tube Fittings are widely used across various industries due to their exceptional strength, lightweight properties, and corrosion resistance. In the aerospace industry, they are employed in hydraulic systems, fuel lines, and structural components due to their ability to withstand high pressures and extreme temperatures. In the chemical and petrochemical industries, they provide reliable, corrosion-resistant solutions for fluid and gas transport. Additionally, their biocompatibility makes them ideal for medical applications, such as implants and surgical equipment. Titanium tube fittings are also used in marine environments for their resistance to seawater corrosion.
Please feel free to contact us if you need any further information or for enquiry.
