Bhavesh Tube Fittings is a reputed manufacturer and supplier based in Dubai, UAE. Specializing in quality stainless steel 304 hydraulic fittings. Known for excellent corrosion resistance, strength and durability, these materials are ideal for a variety of industrial applications including chemical processing, oil and gas, and marine environments. We offer wide range of SS 304 hydraulic fittings designed to provide reliable performance. With a commitment to quality. Bhavesh Tube Fittings offers efficient and cost-effective solutions for all your hydraulic fitting needs.
Stainless steel 304 hydraulic fittings are mainly alloyed with Chromium (18-20%), Nickel (8-10.5%), Carbon, Manganese, Silicon etc. They exhibit impressive mechanical properties with a tensile strength of 515 MPa and excellent yield strength of 205 MPa Offering durability and rigidity. These fittings are highly resistant to corrosion, oxidation and various chemicals, making them suitable for a wide range of applications. The ease of construction, weld, and low maintenance requirements make stainless steel 304 hydraulic fittings a cost-effective and reliable choice for industrial environments.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | SS 304 ,SS 304L |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM) L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY) S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | STAINLESS STEEL 304- EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| TEMPERATURE | STAINLESS STEEL 304 – (-60*C TO 400*C) |
Grade | Mn | C | Si | S | Cr | P | N | Mo | |
| 304 | minimum maximum | – | – | – | – | 18.0 | – | – | – |
| 304L | minimum maximum | – | – 0.030 | – | – | 18.0 | – | – | – |
| 304H | minimum maximum | – | 0.04 | – | – | 18.0 | -0.045 | – | – |
Grade | (% in 50mm) Elongation minimum | 0.2% Proof Yield Strength (MPa) minimum | Strength of Tensile (MPa) minimum | Plate Hardness | |
Brinell (HB) max | Rockwell B (HR B) max | ||||
304 | 40 | 205 | 515 | 201 | 92 |
304L | 40 | 170 | 485 | 201 | 92 |
304H | 40 | 205 | 515 | 201 | 92 |
Grade | British | Euronorm | UNS No. | SS | JIS | ||
European Standards | British Standards | Name | DIN No. | ||||
304 | 58E | 304S31 | X5CrNi18-10 | 1.4301 | S30400 | 2332 | SUS 304 |
304L | – | 304S11 | X2CrNi19-11 | 1.4306 | S30403 | 2352 | SUS 304L |
304H | – | 304S51 | X6CrNi18-11 | 1.4948 | S30409 | – | – |
Contact us to get a quick quote for your requirement.
Stainless steel 304 hydraulic fittings are widely used in applications requiring corrosion resistance and good strength. They are ideal for applications in pharmaceuticals, food and beverages and chemical plants and water treatment plants, where exposure to water and corrosive fluids is common These materials are also used in oil, gas and marine internal performance due to its durability and oxidation resistance . Their versatility ease of construction and ability to maintain integrity over a wide range of temperatures make stainless steel 304 filters a reliable choice for connecting pipes and tubes together in a fluid system.
Please feel free to contact us if you need any further information or for enquiry.
