Bhavesh Tube Fittings is a leading manufacturer and supplier of Copper Check Valves in Dubai, UAE. Our valves are crafted from high-quality copper, ensuring durability and excellent performance in various fluid control applications. We pride ourselves on our commitment to quality and customer satisfaction, providing tailored solutions to meet the specific needs of our clients. With state-of-the-art manufacturing facilities and a skilled team, we ensure that our products adhere to the highest industry standards, making us a trusted partner in the market.
Copper Check Valves are primarily composed of high-purity copper, often with trace amounts of other elements like tin for enhanced strength and corrosion resistance. Their mechanical properties include excellent tensile strength, ductility, and thermal conductivity, making them suitable for various applications. The advantages of Copper Check Valves include superior resistance to corrosion, particularly in plumbing and heating systems, lightweight construction, and the ability to handle high-pressure environments. Additionally, copper’s natural antimicrobial properties contribute to cleaner fluid handling, making these valves ideal for potable water systems.
BRAND NAME | Bhavesh Tube Fittings |
COPPER VALVES SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
CONNECTION | THREADED, TUBE END, SOCKET WELD END, FLANGE END |
COPPER VALVES THREADS | NPT, BSPP, BSPT, METRIC, JIC, UNF |
FLOW PATTERN | STRAIGHT |
COPPER VALVES BODY SHAPE | HEXAGON |
PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI, 20000 PSI |
CRACKING PRESSURE | 0.5 BAR |
COPPER VALVES ORIFICE SIZE | 2 MM TO 40 MM |
COPPER VALVES TYPE | POPPET TYPE, SPRING TYPE |
MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
COPPER VALVES MEDIA TEMPERATURE | (-50* C TO 350*C ) RANGE AS PER PRESSURE |
BODY TYPE | BAR STOCK, FORGED |
PACKING DETAILS | WOODEN PALLET, BOX PACKING |
COPPER VALVES EQUIVALENT BRANDS | SWAGELOK, PARKER, STAUFF, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
MATERIAL | COPPER, CUPRO NICKEL, CUNI 90/10, CUNI 70/30 |
Grade | Zn | Mn | Cu | Ni | Pb | Fe |
---|---|---|---|---|---|---|
Cu-Ni 70-30 | 1 max | 1 max | 65.0 min | 29-33 | .05 max | 0.4-1.0 |
Cu-Ni 90-10 | 1 max | 1.0 max | 88.6 min | 9-11 max | .05 max | 1.8 max |
Cu-Ni 90/10 | Cu-Ni 70/30 | |||
---|---|---|---|---|
Properties | Imperial | Metric | Imperial | Metric |
yield Tensile strength, | 16000-57000 psi | 110-393 MPa | 12800-70100 psi | 88.0-483 MPa |
ultimate, Tensile strength | 43900-60000 psi | 303-414 MPa | 54000-75000 psi | 372-517 MPa |
Machinability | 20% | 20% | 20% | 20% |
at break Elongation | 42.00% | 42.00% | 45.0% | 45.0% |
ratio Poisson’s | 0.34 | 0.34 | 0.34 | 0.34 |
modulus Shear | 7540 ksi | 52.0 GPa | 8270 ksi | 57.0 GPa |
modulus Elastic | 20300 ksi | 140 GPa | 21800 ksi | 150 GPa |
At Bhavesh Tube Fittings, we are the leading supplier, manufacturer, and exporter of Copper Check Valves in Dubai, UAE. Our advanced manufacturing facilities, strategically located in the UAE, allow us to deliver high-quality, customized solutions tailored to your specific needs. With a comprehensive inventory of premium-grade copper materials, we are fully equipped to meet your demands efficiently. Our commitment to excellence and operational efficiency ensures that we consistently maintain sufficient stock to support your business requirements effectively.
COPPER VALVES STANDARD | WNR. | UNS |
---|---|---|
Copper Nickel 90/10 | 2.0872 | C70600 |
Copper Nickel 70/30 | 2.0882 | C71500 |
Bhavesh Tube Fittings is a leading supplier and stockist of premium Copper Check Valves in Dubai, UAE. Our products are widely utilized across various industries, and we are dedicated to delivering exceptional service while ensuring complete customer satisfaction. With our specialized finishing techniques, we set ourselves apart in the metal industry. We are committed to consistently providing top-quality copper valves while efficiently addressing the needs of our clients across diverse sectors.
Contact us to get a quick quote for your requirement.
Copper Check Valves are widely used in plumbing, heating, and HVAC systems to prevent backflow and ensure the efficient flow of liquids. Their corrosion resistance makes them ideal for hot and cold water supply lines, as well as for drainage applications. These valves are also utilized in refrigeration systems, gas pipelines, and chemical processing plants, where they help maintain system integrity by preventing reverse flow. Additionally, their lightweight nature facilitates easy installation, while their durability ensures long-lasting performance in various industrial and residential settings.
Please feel free to contact us if you need any further information or for enquiry.
